Forklift Alternators and Starters - Today's starter motor is normally a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid mounted on it. Once current from the starting battery is applied to the solenoid, basically via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is located on the driveshaft and meshes the pinion using the starter ring gear which is seen on the engine flywheel.
The solenoid closes the high-current contacts for the starter motor, that begins to turn. After the engine starts, the key operated switch is opened and a spring within the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by an overrunning clutch. This allows the pinion to transmit drive in just one direction. Drive is transmitted in this way via the pinion to the flywheel ring gear. The pinion remains engaged, like for instance as the operator did not release the key once the engine starts or if there is a short and the solenoid remains engaged. This causes the pinion to spin separately of its driveshaft.
The actions mentioned above would stop the engine from driving the starter. This significant step stops the starter from spinning really fast that it would fly apart. Unless adjustments were done, the sprag clutch arrangement will preclude utilizing the starter as a generator if it was utilized in the hybrid scheme mentioned earlier. Typically an average starter motor is meant for intermittent use which would prevent it being used as a generator.
Thus, the electrical components are meant to be able to function for just about less than 30 seconds in order to avoid overheating. The overheating results from too slow dissipation of heat because of ohmic losses. The electrical components are designed to save cost and weight. This is the reason the majority of owner's handbooks used for automobiles recommend the operator to pause for at least 10 seconds after each and every 10 or 15 seconds of cranking the engine, if trying to start an engine which does not turn over at once.
In the early part of the 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Before that time, a Bendix drive was used. The Bendix system functions by placing the starter drive pinion on a helically cut driveshaft. Once the starter motor starts turning, the inertia of the drive pinion assembly allows it to ride forward on the helix, hence engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and hence out of mesh with the ring gear.
The development of Bendix drive was developed during the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, developed and launched during the 1960s. The Folo-Thru drive has a latching mechanism along with a set of flyweights inside the body of the drive unit. This was an improvement for the reason that the average Bendix drive used so as to disengage from the ring as soon as the engine fired, even if it did not stay running.
When the starter motor is engaged and begins turning, the drive unit is forced forward on the helical shaft by inertia. It then becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for example it is backdriven by the running engine, and after that the flyweights pull outward in a radial manner. This releases the latch and permits the overdriven drive unit to become spun out of engagement, therefore unwanted starter disengagement can be prevented previous to a successful engine start.
